SONY FCB-EX480CP key feature: 1/4 ” EXview HAD CCD Sensor , 0.44 million effective pixels, 18x optical zoom, 12x digital zoom, Auto ICR (Auto IR-cut Filter Removal), Spherical privacy zone masking, Auto focus.
SONY FCB-EX480CP Product Details:
FCB-EX480CP camera module uses a high sensitivity CCD, which can still take images normally under the minimum illumination of 0.7Lx. The module inherits various convenient functions supported by the previous FCB series camera modules that need to be developed, such as: electronic flip function, alarm function, image freezing function and color to black and white function. In addition, all of these FCB EX series camera modules use lead-free solder and halogen-free mounting versions, enabling lower energy consumption. With excellent image quality and support for a variety of unique and convenient features, the FCB EX series camera modules are the perfect choice for demanding security and surveillance applications both indoors and outdoors.
SONY FCB-EX480CP key feature:
1/4" EXview HADTM CCD
Minimum illumination is 0.7Lx (typically) 216x
zoom (18x optical, 12x digital)
Point Auto Exposure*
Auto IR Filter * (Auto ICR)*
Provides a switch interface for external camera control of the camera module*
Electronic Shutter/ Slow shutter*
allows users to design the following features:
Advanced privacy zone masking function*
Electronic flip function*
Alarm function*
Image freeze function*
Internal/external synchronization*
High-speed serial interface via TTL signal level control (VISCA protocol) 38.4kb/s)*
Standard * for secondary development
Sony FCB camera block
