| Product number |
FCB-EX1020P |
| Camera assembly |
|
| Image Sensor |
Types of |
1/4 ” super HAD ⅡCCD |
| Effective number of pixels |
About 0.44 million pixels |
| Image size (horizontal) |
550 TVL |
| Lens |
36x optical zoom |
| f=3.4mm ( wide-angle end) to 122.4mm ( distal) |
| F1.6 to F4.5 |
| Digital zoom |
12 times ( 432 times after using optical zoom ) |
| Viewing angle ( horizontal ) |
1080p mode |
– |
| 720p mode |
57.8° ( wide-angle end) to 1.7° ( distal) |
| Minimum object distance |
10mm (wide-angle end) to 1500mm (distal) ( default : 320mm) |
| Synchronization system |
Internal/External(V-lock) |
| Minimum illumination (50%) |
High sensitivity mode |
—— |
| Normal mode |
0.4 lx , 0.03 lx ( ICR on) |
| Recommended illumination |
100 lx to 100,000 lx |
| Signal to noise ratio |
50dB or more |
| signal system |
HD |
720p/59.94, 720p/50, 720p/29.97, 720p/25 |
| SD |
NTSC, PAL |
| Video output |
Digital |
Y/Cb/Cr 4:2:2 (Conforms to ITU-R BT656) |
| Analog |
VBS Y/C |
| Camera component control interface |
VISCA ( CMOS 5V class) , baud rate: 9.6 Kbps, 19.2 Kbps, 38.4 Kbps,115.0 Kbps stop bit: 1 bit |
| Electronic shutter speed |
1/1 to 1/10,000 seconds, a total of 22 steps |
| White balance |
Automatic, automatic tracking, indoor, outdoor, outdoor automatic, sodium lamp fixed / automatic, one-button, manual |
| Gain |
Auto/Manual ( -3 to +28 dB, +2 steps/ 16 steps) Maximum gain limit ( +6 dB to +28 dB, +2 dB step / total 12 steps) |
| AE control |
Auto, manual, priority mode ( shutter priority and aperture priority) , brightness, EV compensation, slow AE |
| Focusing system |
Auto ( sensitivity: normal, low) , one-touch auto focus, manual, infinity, interval auto focus, zoom trigger auto focus, focus compensation when ICR mode is on |
| EV compensation |
Have |
| BLC |
Have |
| Aperture control |
16 steps |
| Preset |
6 positions |
| Camera component performance |
|
| Wide-D* |
Yes ( on/off) |
| Image stabilization |
Have |
| StableZoom |
Have |
| Digital output interface |
Have |
| Automatic ICR |
Have |
| Spherical privacy zone shadowing |
Have |
| Noise reduction |
Yes ( on/off ) ( level 5 to 1 off a total of 6 steps) |
| Dynamic frame measurement |
Have |
| Alarm function |
Have |
| Slow AE response |
Yes ( about 5 minutes) |
| Image effects |
Yes ( electronic flip, negative, blackboard, mirror, color enhancement) |
| Image freeze |
Have |
| Slow shutter |
Have |
| Temperature reading |
Have |
| Title display |
Yes ( 20 characters/line, up to 11 lines) |
| Camera component mode display |
Have |
| Button switching control |
no |
| Camera component operation switching |
no |
| General specifications |
|
| Storage temperature |
-20 ° C to 60 ° C |
| Storage humidity |
20% to 95% |
| Operating temperature |
-5 ° C to 60 ° C |
| Operating humidity |
20% to 80% |
| Power requirement |
6.0 V to 12.0 V DC |
| Power consumption |
2.4 W ( zoom/focus does not start) , 5.1 W ( zoom/focus start) |
| weight |
230 g |
| Size ( width x height x depth) |
50.0 x 57.5 x 87.9 mm |
Sony FCB camera block
SONY FCB-EX1020P key feature:
(1) Supports progressive scanning technology
(2) Equipped with digital output interface
(3) Multiple operating modes
(4) Supports enhanced digital cooling function
(5) Wide dynamic function supporting new technology: Automatic wide dynamic, interlaced mode wide Dynamic and progressive mode wide dynamic
(6) support image anti-shake function
(7) high resolution up to 550 TV line
(8) support advanced white balance mode
(9) support -5oC to 60oC operating temperature range
(10) Support temperature reading function
(11) support slow AE response function
(12) support color enhancement function
(13) Continuing the functions supported by the C and D versions
•The EX-view HADTM CCD features 380,000 (NTSC)or 440,000 (PAL) effective picture elements andhigh-sensitivity shooting. The minimum illuminationrequired is 1.4 lux (1/60 s (NTSC),1/50 s (PAL), ICROFF).
•A CCD for shooting a wide dynamic range isemployed to perform progressive or interlacedscanning, and images with a wide dynamic range areobtained by a newly developed image signalprocessor (Wide Dynamic Range function).Furthermore, it is possible to automatically switch tothis Wide Dynamic Range function, which enablesyou to obtain optimal images ranging from the darkareas of a subject to the light areas.
•Low-noise images can be obtained even in low lightenvironments using the 3D Noise Reduction (3D NR+ 2D NR) function.
•A function to output interlaced or progressive imagesby digital output (equivalent to ITU-R BT656) isprovided.
•36×optical zoom (432×with digital zoom)
•A Image Stabilizer function enables stable shooting.
•Supporting external synchronization (V-lock)•Images with a high resolution (550 TV lines) can beobtained using a newly developed Image SignalProcessor for improved picture quality.
•An infrared (IR) Cut-Filter can be disengaged fromthe image path for increased sensitivity in low lightenvironments. The ICR will automatically engagedepending on the ambient light, allowing the camerato be effective in day/night environment.
•VISCA is a communications protocol, which enablesthe camera to be controlled remotely from a hostcomputer/controller.•Six memory locations are provided to temporallysave and recall up to six sets of camera settings.
•A Privacy Zone Masking function (max. 24 blocks) isavailable.
•A mosaic masking function has been added to theprivacy zone masking function.
