Sony FCB-EH3150(FCBEH3150) HD Auto focus camera block

Category: Full HD Camera

SONY FCB-EH3150 key feature: 1/4.0" type Exmor CMOS image sensor, 1.43 million effective pixels, 12x optical zoom, 12x digital zoom, Supports all HD modes up to 720p60, Noise reduction, Auto ICR (Auto IR-cut Filter Removal), Spherical privacy zone masking, Wide Dynamic, Auto focus.
Live Chat

SONY FCB-EH3150 Product Details:

Sony FCB-EH3150 High Definition Colour Camera Block. And the smallest camera in the FCB-EH Series is the affordable FCB-EH3150.

And the smallest camera in the FCB-EH Series is the affordable FCB-EH3150. Along with its HD resolution sensor, it features a 12x optical zoom lens.

Sony FCB-EH3150,1.43 million, 1/4 "Exmor CMOS, 12x, HD integrated movement; wide dynamic, noise reduction; suitable for all kinds of ball machines, all-in-one machines, PTZ products, etc.; it can be used in security, intelligent transportation, unmanned flight equipment, snapshot kiosk, police car, amblyopia, video conference and other fields.

Sony fcb-eh3150 and fcb-ch3150 technical parameter manual

These camera components integrate many features of Sony's award-winning FCB series, such as wide dynamic function, automatic color to black and privacy area masking function. With a wide selection space, users can easily select the appropriate Sony camera component products for their specific applications.

Sony FCB-EH3150 High Definition Colour Camera Block

SONY FCB-EH3150 key feature:

Simple connection

One cable, one interface

  • Use a cable to transmit video, VISCA communication control signals, and power.
  • Supports 30-pin mini coaxial cable ( digital and analog output ) and 24-pin FFC ( analog output only ) *1 interface.

Video mode fast switching function
Use this function to change the video mode without restarting the machine continuously, for example, from 720p/25 mode to 720p/59.94 mode. This feature allows users to soft to change the video resolution of the camera component parts reset function.

Sony FCB-EH3150 FCB-CH3150 High Definition Colour Camera Block

SONY FCB-EH3150 Other properties:



  • Multiple white balance modes ( automatic, automatic tracking, indoor, outdoor, outdoor automatic, sodium fixed/automatic, one-button, manual )
  • Picture effects ( electronic flip, negative, black and white, mirror, color enhancement )
  • Picture freeze
  • Temperature reading
  • Slow AE response (up to approximately 5 minutes )
  • Title display ( 20 characters per line, up to 11 lines )
  • Camera component mode display ( English )
  • Electronic shutter / slow shutter
  • Spot AE
  • High resolution mode
  • Infrared light focus correction function
  • 4 preset gamma control values
  • 4 chroma suppression levels

Sony fcb-eh3410(fcbeh3410) auto focus camera block - Full HD Camera - 2

fcb-eh series features a series of 20x to 28x optical zoom lens components with outstanding performance required for security, intelligent transportation, unmanned aerial vehicles, picture kiosks, police cars, low vision and video conferencing applications.

The fcb-eh3150 camera assembly is equipped with a 1/4-inch Exmor CMOS imager with a resolution of 720p, and integrates many features of Sony’s award-winning FCB series, such as wide-d (wide dynamic range), automatic ICR and privacy area masking.

Sony fcb-eh3150 HD sensitivity element 1/4 “Exmor CMOS camera with optical magnification of 12 times (F = 3.7-44.4 mm / f1.6-f2.5 image size (1280×720,720 × 480,720 × 576), effective pixels: 1.43 mpix.
