Uav special IP interface board Product Details:
Uav special IP interface board is used for the high-definition digital integrated camera core of the SONY FCB EV/CV EH/CH series. The LVDS interface is connected to the movement. After the camera video format is configured, the HD video format can be simultaneously transmitted through the HDMI and the network port. Output, also supports other brand movements of the SONY VISCA protocol.
Uav special IP interface board is used for the high-definition digital integrated camera core of the SONY FCB EV/CV EH/CH series. The LVDS interface is connected to the movement. After the camera video format is configured, the HD video format can be simultaneously transmitted through the HDMI and the network port. Output, also supports other brand movements of the SONY VISCA protocol.
Uav special IP interface board Main features:
1. Support Sony FCB HD series and compatible camera image signal acquisition, encoding and network transmission, providing rich application interface such as voice bidirectional/USB/TF card/alarm input and output.
2. Up to two serial ports are convenient for direct control of the camera and code board. The IE interface supports serial port transparent transmission, and can directly input commands to control the camera in the interface.
3, up to 1080P60 resolution display, storage, transmission.
4, fully open OSD function, up to 10 areas, each area can display 4 lines of text, each line can display 128 characters.
5, camera, video storage can be controlled by serial command mode, convenient for customers to carry out secondary development .
6, H.264 and H.265 two encoding formats are optional.
7, support for motion detection alarms, picture capture.
8, support P2P cloud management platform, support mobile phone remote access.
9, support full Netcom and ONVIF protocol, compatible with multiple client software and NVR.
10. Support the private centralized monitoring platform and support the national standard 28181 agreement (optional).
11, support WEB configuration, support OTA online upgrade.
12, free PC / mobile client software / SDK, provide windows, linux, Android, ISO platform SDK. Convenient for customers to re-develop access to third-party platforms.

Sony FCB camera block
