4K UHD Surgical Video Camera 6G SDI+4K HDMI (Remote Control Version) Application
Widely used in clinical medical operating room, remote teaching, clinical skills training, dentistry,teaching,pet surgery scene video recording,scientific research and clinical assistance in hospitals or medical schools such as medical aesthetics.
4K UHD Surgical Video Camera 6G SDI+4K HDMI (Remote Control Version) Features
Adopt SONY’s new generation 1/2.5 Type “Exmor” CMOS Sensor，20x optical zoom (medical grade), 12x digital zoom
Up to 4K Ultra HD video image format, up to 8.51 mega effective pixels.High-quality images with a maximum resolution of 3840X2160 can be achieved.
Automatic, fast and precise focusing, true color reproduction under high brightness, automatic strong light suppression function.
The scene shooting mode can be customized according to the user’s needs, and the multi-scene mode can be switched quickly.
Simple operation interface, multi-functional touch key panel with high zero sensitivity.Convenient and fast debugging, scene switching, focusing, zoom and other functions.
2.4G wireless remote control without dead angle control, to solve the traditional cable constraints.
The special control software for shadowless lamp perfectly solves the problem of light spots in the surgical field.(Software note number of HD surgical field camera control system: 2017SR557533)
Laser cross cursor auxiliary positioning system, to solve the difficulty that the camera can not aim at the surgical field.
(Auxiliary positioning system patent No.: ZL 2017 2 1638974. 8)
Integrated design, in line with ergonomics, no dust, easy to clean. Standard ONDAL. spring arm docking bracket makes the instalation easy.
(Appearance patent number: ZL 2017 3 0146926. 6 Appearance patent number: ZL 2018 3 0234305. 8)
VOLERS HD video recording system supports external pickup and sound box to realize real-time audio intercom between operating room and demonstration room; It also supports real-time audio and video recording.
RS485 control, PELCO control protocol.
4K UHD Surgical Video Camera 6G SDI+4K HDMI (Remote Control Version) Button Functions
4K UHD Surgical Video Camera 6G SDI+4K HDMI (Remote Control Version) Product accessories
Specifications
| Image sensor | 1/2.5 Type “Exmor” CMOS with progressive mode |
| Signal system | 2160P/29.97,2160P25,1080p/59.94,1080p/50,1080p/29.97,1080p/25,1080i/59.94, 1080i,720p/59.94, 720p/50, |
| Number of effective pixels | About 8.51 megapixels (16:9) |
| Focus mode | Support manual focus and autofocus (AF) |
| Lens focal length | 20x optical, 12x electronic magnification F=4.4mm to 88.4 mm, F2.0 to F3.8 |
| Dynamic range | Dynamic Range Extender (DRS) , combine the image from the darkest and brightness area |
| Electronic Shutter | 1/25、1/50、1/100、1/120、1/150、1/300、1/1000、1/2000、1/4000、1/10000,etc. |
| White balance | Auto, ATW, Indoor, Outdoor, One，Push WB, Manual WB,Outdoor，Auto |
| Video signal | 6G SDI+HDMI output simultaneously |
| Remote control | RS485 communication, capable to control the camera remotely |
| Control Protocol | PELCO-P/D protocol |
| Power source | DC12V~24V 1.5A |
| Power | Approx. 6.8 W |
| Operating temperature | -5 ° C to 60 ° C |
| Storage temperature | -20 ° C to 65 ° C |
| Size | 225*120*195mm(without adapter hook and sterilization handle) |
| Net Weight | about 3.5KG |
